Super Ceramic Saddle Ring

ceramic super saddle is widely used in drying tower, absorbing tower and cooling tower in the fields of chemical, petrochemicl,Coal gas etc industries.

Quantity:
  • Chemshun
  • 69091100
  • Ceramic
  • Random Packing
  • Supper Ceramic Saddle
  • 25/38/50/76mm
  • 980 Degree Centigrade
1: Product Description Description

Ceramic intalox saddle is improved from the arc saddle, it changes the both arched surface to rectangular surface and makes the interior and exterior radius of curvature different, this construction overcomes the problem of nesting basically, it makes porosity distributed even and improves the distribution of the fluid , greater capacity and lower pressure drop than Raschig ring.

Chemshun
 ceramic intalox saddle has excellent acid resistance and heat resistance.It can resist to corrosion of various inorganic acids, organic acids and organic solvents except hydrofluoric acid, and can be used in high or low temperature conditions, which have been used widely.

2: Product Characters

--  Favorable liquid distributing capability
-- Chemical and acid resistance
-- Lower pressure drop
-- High thermal stress resistance


3: Geometric properties
Size

D*H*δ

Specific Surface

Void Volume

Bulk Number

Bulk Density

Dry Packing Facorm

mm

mm

m2/m3

%

n/m3

Kg/m3

m-1

16

25×25×2.2

378

71

269900

686

1056

25

40×20×3

200

77.2

58230

544

434.6

38

60×30×4

131

80.4

19680

502

252

50

80×42×6

105.4

79.1

8243

470

212.9

4:  Applicant

1.)   Regenerative Thermal Oxidizers
2.)   Acid Gas Scrubbers
3.)   Dryer Towers
4.)  Tail Gas Scrubbers
5.)   Impasse Towers

5:  Technical Data :

Al2O3

SiO2

Fe2O3

CaO

K2O+Na2O

TiO2

MgO

17%-23%

>70%

<1%

1-2%

2-4%

<0.5%

<2.5%


Moh’s hardness (scale)

Bulk Gravity(g/cm3)

Water absorption

Ignition loss

Heat resistance

Alkali Resistance

Acid Resistance

≥6.5

2.1~2.4

<0.9%

≤0.3%

Up to 980℃

>80%

> 98%

6: Package Way

  >   Ton Bags                      >   Plastic Bags
  >   Paper Box                    >   Wooden Box
