Chemshun Ceramics
>> Detailed description :
Wavy Ceramic Baffle Ring resistant against various acid (except fluorine acid), organic solution, with high density and excellent resistance performance to acid and thermal. Which have been widely used in drying tower, absorption tower, cooling tower and recycle tower of chemical industries, metallurgy, coal gas and environmental protecting etc
>> Product characters
1) Allow large quantity flow distribution.
2) Low pressure drop
3) High efficiency
>> Geometric properties
| Size | Surface Area m2/m3 | Porosity % | Bulk density kg/m3 | Quantity/m3 |
| 50*50*5 | 145 | 50 | 560 | 6400 |
| 80*80*8 | 120 | 56 | 780 | 1950 |
| 100*100*10 | 110 | 53 | 810 | 1000 |
| 120*120*12 | 75 | 55 | 820 | 370 |
| 150*150*15 | 60 | 58 | 950 | 295 |
>> Applicant
- Co2 degassing tower
- Ozone contact reaction tower
- Acid mist purification tower,
- The synthetic reaction tower packing
>> Chemical Composition:
| Al2O3 | SiO2 | Fe2O3 | CaO | K2O+Na2O | TiO2 | MgO |
| 17%-23% | >70% | <1% | 1-2% | 2-4% | <0.5% | <2.5% |
>> Physical properties:
| Moh’s hardness (scale) | Bulk Gravity(g/cm3) | Water absorption | Ignition loss | Heat resistance | Alkali Resistance | Acid Resistance |
| ≧6.5 | 2.1~2.4 | <0.9% | ;0.3% | Up to 980℃ | >80% | >98% |
